90,45 Degree Curved Connector
Material: Brass / Brass with nickel Plated ( Furnished with insulating Liner)
Protection Degree: IP67
When place the order, please inform the dimension of the conduit and the connected thread, such as JX15-G1/2’’.
Product
Material: Brass / Brass with nickel Plated ( Furnished with insulating Liner)
Protection Degree: IP67
Note:One end is connected to the conduit and the other end is connected to the chest, Electricity machine and other equipment in 90 degree or in 45 degree.
When place the order, please inform the dimension of the conduit and the connected thread, such as JX15-G1/2’’.
|
90/45 Degree Curved – Metric ,G Thread |
|||||
|
Product Code |
Specification |
Connection for Thread |
Std. Pkg (pcs) |
||
|
Metric Thread |
English |
G Thread |
Metric Thread |
||
|
JX-W90-12 |
Φ12 |
3/8’’ |
G3/8’’ |
M16 |
20 |
|
JX-W90-15 |
Φ15 |
1/2’’ |
G1/2’’ |
M20 |
20 |
|
JX-W90-20 |
Φ20 |
3/4’’ |
G3/4’’ |
M25 |
20 |
|
JX-W90-25 |
Φ25 |
1’’ |
G1’’ |
M32 |
10 |
|
JX-W90-32 |
Φ32 |
1-1/4’’ |
G1-1/4’’ |
M40 |
10 |
|
JX-W90-38 |
Φ38 |
1-1/2’’ |
G1-1/2’’ |
M50 |
5 |
|
JX-W90-51 |
Φ51 |
2’’ |
G2’’ |
M63 |
2 |
|
JX-W90-64 |
Φ64 |
2-1/2’’ |
G2-1/2’’ |
M76 |
2 |
|
JX-W90-75 |
Φ75 |
3’’ |
G3’’ |
M88 |
1 |
|
JX-W90-100 |
Φ100 |
4’’ |
G4’’ |
M114 |
1 |
